Benelec UHF 2.5dBd Short Boom Base Folded Dipole Antenna with Stainless Steel Bracket 360-520MHz, N Plug
AUD Includes GST
The Benelec 02680AS is a heavy-duty UHF base antenna designed for broadband performance across the 360–520 MHz band. Constructed entirely from electropolished stainless steel, it offers exceptional durability in harsh or corrosive environments. The antenna features a short boom with selectable mounting positions (¼ and ½ wavelength) to optimise the H-plane radiation pattern. Factory-tuned and supplied with a stainless-steel right-angle mounting bracket, the 02680AS is ideal for low-gain, wide-beamwidth base station applications.
[shipping_message]
We’re currently enabling online payment and shipping.
Shipping available:
- Description
- Specifications
Description
Benelec UHF 2.5dBd Short Boom Base Folded Dipole Antenna
with Stainless Steel Bracket | 360-520MHz | N Plug
FEATURES
- All electropolished stainless-steel
- Broad H-plane pattern
- Rugged construction
- Broad VSWR bandwidth
- Mounting markers ¼ and ½ wavelength
- Right angle stainless-steel mounting bracket included
- Factory tuned; requires no further tuning
- Designed and manufactured in Australia
APPLICATION
Wide beamwidth, low gain, base station applications.
WARRANTY
3-Year Warranty
(Refer to Benelec Terms and Conditions)
| Frequency | 360 – 520 MHz |
| Gain | Unity (0 dBd) |
| VSWR | < 1.5:1 |
| Impedance | 50 Ω nominal |
| Polarisation | Vertical |
| E-Plane Beamwidth | 80° |
| H-Plane Beamwidth | Directional – see radiation patterns |
| Power | 500 W |
| Termination | N plug connector |
| Cable | RG-213 cable tail |
| Wind Loading | 0.02290 SQM 2.5 kg (24.887 N) @160 kph |
| Base Material | Stainless-steel |
| Length | 520 mm |
| Net Weight | 1.2 kg |
