Benelec UHF 9dBd Corner Reflector 380-490MHz, N Socket
AUD Includes GST
The 02688Q is a heavy-duty 90° corner reflector antenna designed for applications requiring high front-to-back ratio and strong forward gain. It is well suited for reducing unwanted interference from nearby communication sites while maintaining excellent forward signal performance.
[shipping_message]
We’re currently enabling online payment and shipping.
Shipping available:
- Description
- Specifications
Description
Benelec UHF 9dBd Corner Reflector
380 – 490 MHz | N Socket
FEATURES
- All stainless-steel construction
- High forward gain
- High front to back ratio
- Rugged feed system
- Disassembles for ease of transport
- RG213 cable tail
- Mounting clamps included
- Factory tuned, no further tuning required.
- Designed and manufactured in Australia
APPLICATION
Base station.
WARRANTY
3-Year Warranty
(Refer to Benelec Terms and Conditions)
| Frequency | 380 – 490 MHz |
| Gain | 9 dBd (11 dBi) |
| VSWR | < 1.6:1 |
| Impedance | 50 Ω nominal |
| Polarisation | Vertical / horizontal |
| Termination | N socket / RG213 tail |
| Base Material | All stainless-steel |
| Power Rating | 500 W |
| Wind Loading | 458 N @ 160 kph |
| Dimensions | 1020 x 1020 x 670 mm |
| Net Weight | 12 kg |
