Benelec UHF 4.5dB Mobile Ground Plane Antenna 400-420MHz, 5/16” 26 TPI Female Thread
AUD Includes GST
The 02620IBK Antenna Series offers a genuine 4.5dB of gain. This antenna is roof-mounted, covering all UHF commercial Mobile Radio Bands. This antenna is designed for optimum performance on Benelec’s 02740 UHF Mobile Base and covers all the respective bands of operation under 1.5:1 VSWR. This antenna has a Black Stainless-Steel construction, ensuring a robust and flexible finish.
[shipping_message]
We’re currently enabling online payment and shipping.
Shipping available:
- Description
- Specifications
Description
Benelec UHF 4.5dB Mobile Ground Plane Antenna
400-420MHz
FEATURES
- Black stainless-steel finish
- Black chromed brass ferrule to suit standard Benelec 5/16” 26 TPI base (02740)
- Spring included to ensure flexibility, durability, and a robust finish
- Factory tuned; requires no further tuning
- Designed and manufactured in Australia
APPLICATION
Mobile coverage for the UHF 400 – 420 MHz commercial radio bands.
WARRANTY
3-Year Warranty
(Refer to Benelec Terms and Conditions)
| Frequency | 400 – 420 MHz |
| Gain | 4.5 dB |
| VSWR | <1.5:1 |
| Impedance | 50 Ω |
| Vertical Beamwidth | 15° |
| Tuned Bandwidth | 20 MHz |
| Termination | 5/16” 26 TPI female thread |
| Length | 763mm |
| Net Weight | 150g |
